这一节，主要聊Acceptor。

主要功能是：接收请求，创建socket连接，并且分配给Processor处理。

/** * Thread that accepts and configures new connections. There is one of these per endpoint. */private[kafka] class Acceptor(val endPoint: EndPoint,                              val sendBufferSize: Int,                              val recvBufferSize: Int,                              brokerId: Int,                              processors: Array[Processor],                              connectionQuotas: ConnectionQuotas) extends AbstractServerThread(connectionQuotas) with KafkaMetricsGroup {  private val nioSelector = NSelector.open()//注册监听socket的Selector对象!!!  val serverChannel = openServerSocket(endPoint.host, endPoint.port)//监听套接字！！！  this.synchronized {//启动其管辖的Processor线程    processors.foreach { processor =>      Utils.newThread(s"kafka-network-thread-$brokerId-${endPoint.listenerName}-${endPoint.securityProtocol}-${processor.id}",        processor, false).start()    }  }

接下来，它的run方法是Acceptor的核心逻辑，我们看看具体实现：

/**   * Accept loop that checks for new connection attempts   */  def run() {    serverChannel.register(nioSelector, SelectionKey.OP_ACCEPT)//注册ACCEPT事件    startupComplete()    try {      var currentProcessor = 0      while (isRunning) {        try {          val ready = nioSelector.select(500)//最多等待500毫秒的时间，看是否有socket过来！          if (ready > 0) {            val keys = nioSelector.selectedKeys()            val iter = keys.iterator()            while (iter.hasNext && isRunning) {              try {                val key = iter.next                iter.remove()                if (key.isAcceptable)                  accept(key, processors(currentProcessor))                else                  throw new IllegalStateException("Unrecognized key state for acceptor thread.")                // round robin to the next processor thread                currentProcessor = (currentProcessor + 1) % processors.length//看来也是采用轮询的方案              } catch {                case e: Throwable => error("Error while accepting connection", e)              }            }          }        }

小贴士:

我们类比下Thrift的方案

/**   * A round robin load balancer for choosing selector threads for new   * connections.   */  protected static class SelectorThreadLoadBalancer {    private final Collection
     threads;    private Iterator
     nextThreadIterator;    public

      SelectorThreadLoadBalancer(Collection

       threads) {      if (threads.isEmpty()) {        throw new IllegalArgumentException("At least one selector thread is required");      }      this.threads = Collections.unmodifiableList(new ArrayList

       (threads));      nextThreadIterator = this.threads.iterator();    }    public SelectorThread nextThread() {      // Choose a selector thread (round robin)      if (!nextThreadIterator.hasNext()) {        nextThreadIterator = threads.iterator();      }      return nextThreadIterator.next();    }  }}一旦到了最后，就回绕到第1个




可见，殊途同归，不解释！

接下来，重点就是accept函数

/*   * Accept a new connection   */  def accept(key: SelectionKey, processor: Processor) {

为了顺利进来，我们先打个断点如下：

stop in kafka.network.SocketServer$Acceptor.acceptstop in kafka.network.SocketServer$Acceptor.runstop at kafka.network.SocketServer:335stop at kafka.network.SocketServer:265

/*   * Accept a new connection   */  def accept(key: SelectionKey, processor: Processor) {    val serverSocketChannel = key.channel().asInstanceOf[ServerSocketChannel]    val socketChannel = serverSocketChannel.accept()//调用accept函数获取 socket句柄    try {      connectionQuotas.inc(socketChannel.socket().getInetAddress)      socketChannel.configureBlocking(false)      socketChannel.socket().setTcpNoDelay(true)      socketChannel.socket().setKeepAlive(true)      if (sendBufferSize != Selectable.USE_DEFAULT_BUFFER_SIZE)        socketChannel.socket().setSendBufferSize(sendBufferSize)      debug("Accepted connection from %s on %s and assigned it to processor %d, sendBufferSize [actual|requested]: [%d|%d] recvBufferSize [actual|requested]: [%d|%d]"            .format(socketChannel.socket.getRemoteSocketAddress, socketChannel.socket.getLocalSocketAddress, processor.id,                  socketChannel.socket.getSendBufferSize, sendBufferSize,                  socketChannel.socket.getReceiveBufferSize, recvBufferSize))      processor.accept(socketChannel)//交给Processor处理，这个已经是通过轮询选中的    } catch {      case e: TooManyConnectionsException =>        info("Rejected connection from %s, address already has the configured maximum of %d connections.".format(e.ip, e.count))        close(socketChannel)    }  }

我们看Processor怎么处理的

/**   * Queue up a new connection for reading   */  def accept(socketChannel: SocketChannel) {    newConnections.add(socketChannel)    wakeup()  }

这个newConnections是个什么？

private val newConnections = new ConcurrentLinkedQueue[SocketChannel]()

是1个队列，恩，类比下Thrift怎么玩的

看到了吧，套路都一样。。。

那么， 这个新的连接是怎么被Processor处理的呢？

看代码

奥秘就在这里，我们再看看Thrift的玩法

真的没啥可说的，就这么回事吧

好，回到Kafka，我们知道Processor主要完成读取请求和写回响应。

Processor不参与具体的业务逻辑操作。

通过acceptor.accept创建的socket,通过processor.accept传给processor处理，

/**   * Register any new connections that have been queued up   */  private def configureNewConnections() {    while (!newConnections.isEmpty) {      val channel = newConnections.poll()      try {        debug(s"Processor $id listening to new connection from ${channel.socket.getRemoteSocketAddress}")        val localHost = channel.socket().getLocalAddress.getHostAddress        val localPort = channel.socket().getLocalPort        val remoteHost = channel.socket().getInetAddress.getHostAddress        val remotePort = channel.socket().getPort        val connectionId = ConnectionId(localHost, localPort, remoteHost, remotePort).toString        selector.register(connectionId, channel)//注册读事件      } catch {        // We explicitly catch all non fatal exceptions and close the socket to avoid a socket leak. The other        // throwables will be caught in processor and logged as uncaught exceptions.        case NonFatal(e) =>          val remoteAddress = channel.getRemoteAddress          // need to close the channel here to avoid a socket leak.          close(channel)          error(s"Processor $id closed connection from $remoteAddress", e)      }    }  }

到这里，就注册了读事件，然后看Processor怎么处理读事件的！

private def processCompletedReceives() {    selector.completedReceives.asScala.foreach { receive =>      try {        val openChannel = selector.channel(receive.source)        // Only methods that are safe to call on a disconnected channel should be invoked on 'openOrClosingChannel'.        val openOrClosingChannel = if (openChannel != null) openChannel else selector.closingChannel(receive.source)        val session = RequestChannel.Session(new KafkaPrincipal(KafkaPrincipal.USER_TYPE, openOrClosingChannel.principal.getName), openOrClosingChannel.socketAddress)        val req = RequestChannel.Request(processor = id, connectionId = receive.source, session = session,          buffer = receive.payload, startTimeNanos = time.nanoseconds,          listenerName = listenerName, securityProtocol = securityProtocol)        requestChannel.sendRequest(req)//发给业务线程池,是通过requestChannel        selector.mute(receive.source)      } catch {        case e @ (_: InvalidRequestException | _: SchemaException) =>          // note that even though we got an exception, we can assume that receive.source is valid. Issues with constructing a valid receive object were handled earlier          error(s"Closing socket for ${receive.source} because of error", e)          close(selector, receive.source)      }    }  }

/** Send a request to be handled, potentially blocking until there is room in the queue for the request */  def sendRequest(request: RequestChannel.Request) {    requestQueue.put(request)  }

可见，把请求放入了队列，跟Thrift一模一样的

接下来，看这个队列如何被业务线程获取拿任务处理的！

在此之前，有1个细节

这个跟Thrift完全是一模一样啊

手法如出一辙。

回到kafka的代码，既然请求已经放到一个队列里了，那么就看业务线程如何处理了，下一节讲这个
